PANZER TRACTS N.5-3 - PZ.KPFW. PANTHER AUSFUHRUNG G

DI PROSSIMA PUBBLICAZIONE - ESTATE 2024

For Panzer Tracts No.5-3: Panzerkampfwagen Panther Ausführung G, Thomas Jentz and Hilary Doyle spent hundreds of hours precisely measuring surviving Panther Ausf.G’s, and over a thousand hours drawing at full scale to create as-built drawings for the first time – accurate to the same tolerances demanded of the original assembly firms. Hundreds of research hours went into finding the numerous previously unnoticed modifications.

The team selected the unique approach of using 1:10 scale CAD drawings to illustrate the smallest details, while six-view (including right side and belly) 1:35 scale drawings are used for the complete Panther. They also created ‘flat-plane’ drawings of many components to assist modellers in making accurate parts that are hard to replicate when only drawn at an angle.

This book is the definitive reference for the Panther Ausf.G and F.G.1250 infra-red scope and sight with over 200 scale CAD drawings and many clear/rare large-format photos. This data is subject to change before publication.
