Detailed in the Original Builders' Plans

Autore: David Hobbs

Codice: 220302

€ 35,00

Minuzioso studio tecnico della portaerei inglese HMS Victorious realizzato attraverso la raccolta dei dettagliatissimi piani e dei disegni originali a colori.


The technical details of British warships were recorded in a set of plans produced by the builders on completion of every ship. Known as the as fitted general arrangements, these drawings represented the exact appearance and fitting of the ship as it entered service. Intended to provide a permanent reference for the Admiralty and the dockyards, these highly detailed plans were drawn with exquisite skill in multi-coloured inks and washes that represent the acme of the draughtsman s art. Today they form part of the incomparable collection of the National Maritime Museum at Greenwich, which is using the latest scanning technology to make digital copies of the highest quality. This book is one of a series based entirely on these draughts which depict famous warships in an unprecedented degree of detail complete sets in full colour, with many close-ups and enlargements that make every aspect clear and comprehensible. Extensive captions point the reader to important features to be found in the plans, and an introduction covers the background to the design. HMS Victorious was a ship with two almost separate incarnations as built in 1941 she was one of a new type of armoured carrier which saw strenuous wartime service; post-war the ship underwent a massive reconstruction lasting nearly eight years that saw her recommission in1958 as one of the best equipped carriers in the world, ready for another decade of duty. Both these phases of the ship s life are fully documented, which allows this novel form of anatomy to cover two generations of carrier design.




100 tra piani di ricostruzione e disegni al tratto




24,5 x 29
